leagend BC811 is a high-performance charger designed for various 12V lead-acid batteries. Equipped with WiFi connectivity, it allows users to monitor and control the charging process remotely via a smartphone app.
leagend BC811 supports real-time data display, including charging current, voltage, and power. With a maximum stable charging current of 8A, it offers efficient and reliable charging.
The IP65 waterproof rating makes it suitable for wet environments. And its additional features include battery repair mode, overvoltage, overcurrent, and overheat protection, along with automatic temperature compensation for both cold and hot climates.
leagend BC811 supports real-time data display, including charging current, voltage, and power. With a maximum stable charging current of 8A, it offers efficient and reliable charging.
The IP65 waterproof rating makes it suitable for wet environments. And its additional features include battery repair mode, overvoltage, overcurrent, and overheat protection, along with automatic temperature compensation for both cold and hot climates.
12V Wi-Fi LEAD-ACID BATTERY CHARGER
- This is a lead-acid battery charger, which can charge various 12V lead-acid batteries;
- This Wi-Fi charger can send real-time charging information to the phone app. Users can remotely start and stop charging, select the charging current, view the charging current, power, etc.;
- 8A maximum stable charging current;
Smart mode
-
Smart unattended mode, which can stay connected for a long time;
-
Provides battery repair mode;
-
The output power is automatically reduced when the charger temperature is too high;
Built-in features
-
Built-in protection of overvoltage, overcurrent, overheat and reverse connection;
-
Built-in high and low temperature automatic compensation mechanism, which can automatically handle special situations such as low temperature in winter and high temperature in summer;
waterproof
With IP65 waterproof, the charger can be used in wet environment;
PRODUCT PARAMETERS
Input
100~240V-AC/50-60Hz
Charging Voltage
Motorcycle and car: 14.4V; AGM: 14.7V; Repair: 15.8V; Float: 13.6V
Working Temperature
-20℃~50℃ (-4℉~167℉)
Charger Type
All types of 12V lead-acid batteries
Battery Capacity
1.2-260Ah
Protection Class
IP65
WIFI Standard
IEEE 802.11 b/g/n
WIFI Frequency
2.4GHz
Maximum Charging Current
8A
Max Current of Unattended Mode
4A
Reverse Leakage Current
<1.5Ah/month
